Set Appliance State:
Gas Off
Turn Hot Water Tap On
Isolate Mains Power to appliance as per TOPs P4
Attach pressure gauge to the inlet pressure test point
DHW temperature control to MAX
Attach pressure gauge to the inlet pressure test point
DHW temperature control to MAX
Gas On
| WARNING! - Mains voltage is expected during test follow TOPs P4 live testing procedure |
Observation:
Allow ignition sequence to commence.
Does the inlet pressure remain above 18mb throughout the ignition sequence?
Note:
When pressure gauge is removed the pressure test point should be tightened and checked for gas tightness.
Does the inlet pressure remain above 18mb throughout the ignition sequence?
Note:
When pressure gauge is removed the pressure test point should be tightened and checked for gas tightness.
Isolate as per TOPs P4
and refit as necessary
