Set Appliance State:
Mains Power Off
Turn Hot Water Tap On
On/Off Switch in ON position
Mode Selector Switch to Summer
Heating Thermostat set to MAX
Mode Selector Switch to Summer
Heating Thermostat set to MAX
| WARNING! Mains voltage is expected during test, follow TOPs P4 live testing procedure |
Observation:
Does burner remain alight?
NOTE:
If the boiler goes to lockout-reset by switching the On/Off switch to OFF for approximately 10 seconds and then ON again.
NOTE:
If the boiler goes to lockout-reset by switching the On/Off switch to OFF for approximately 10 seconds and then ON again.
