Set Appliance State:
| Isolate Mains Power to appliance as per TOPs P4 |
CH Demand
Selector Switch to Hot Water and Heating
Boiler CH thermostat set to MAX
Attach temperature clamps to flow and return pipes just below primary thermistor
Boiler CH thermostat set to MAX
Attach temperature clamps to flow and return pipes just below primary thermistor
| WARNING! - Mains voltage is expected during test follow TOPs P4 live testing procedure |
Observation:
Allow boiler and system to heat.
Does the boiler have a temperature differential of approximately 20°C or lower?
Does the boiler go to lockout again?
Does the boiler have a temperature differential of approximately 20°C or lower?
Does the boiler go to lockout again?
