Set Appliance State:
CH Demand
CH Temperature control set to MAX
Gas On
| WARNING! - Mains voltage is expected during test follow TOPs P4 live testing procedure |
Observation:
Reset appliance as necessary.
Listen carefully to the appliance as it goes through its ignition cycle.
The burner should be heard to ignite and then establish which should be indicated by a flame symbol appearing on the top right of the display.
If the flame symbol does not appear after the burner ignites this indicates a rectification issue.
Once lit the flame should not baffle or be excessively noisy as this indicates a combustion issue.
Note:
The sparking on this appliance can be very quiet. If you are not sure if sparking is present click here for a test to check.
Listen carefully to the appliance as it goes through its ignition cycle.
The burner should be heard to ignite and then establish which should be indicated by a flame symbol appearing on the top right of the display.
If the flame symbol does not appear after the burner ignites this indicates a rectification issue.
Once lit the flame should not baffle or be excessively noisy as this indicates a combustion issue.
Note:
The sparking on this appliance can be very quiet. If you are not sure if sparking is present click here for a test to check.
