Set Appliance State:
Mains Power Off
Turn Hot Water Tap On
CH temperature selector to 0 position
DHW temperature selector to 0 position
DHW temperature selector to 0 position
| WARNING! Mains voltage is expected during test, follow TOPs P4 live testing procedure |
Observation:
Reset lockout as necessary.
Allow appliance to self check and return to standby mode.
DHW temperature selector to maximum position.
Does the burner ignite and remain alight for more than eight seconds?
Allow appliance to self check and return to standby mode.
DHW temperature selector to maximum position.
Does the burner ignite and remain alight for more than eight seconds?
