Adjust, Service, Repair or Replace as necessary
Isolate Mains Power to appliance as per TOPs P4
Isolate Water and Gas as appropriate

Location:
The Fixed limit Thermostat is situated within the electrical control box to the right of the PCB and the Domestic Hot Water Thermostat, connected with blue wires.
Upon completion of the fault diagnostics carry out final electrical safety tests and checks as per TOPs (C6).
Part Number: GC264602


Refer to ADAPT for further information.
