Set Appliance State:
Mains Power Off
CH Demand
Selector switch in winter position
CH temperature adjustment knob full anticlockwise (max heat)
Timer switched to FIX ON
CH temperature adjustment knob full anticlockwise (max heat)
Timer switched to FIX ON
| WARNING! Mains voltage is expected during test, follow TOPs P4 live testing procedure |
Observation:
Within approximately 45 seconds, does the burner lift from low flame to high flame?
