Set Appliance State:
Turn Hot Water Tap On
Isolate Mains Power to appliance as per TOPs P4
Reconnect the Flame Sense Electrode Lead
Boiler On/Off Switch ON
Reconnect the Flame Sense Electrode Lead
Boiler On/Off Switch ON
| WARNING! Mains voltage is expected during test, follow TOPs P4 live testing procedure |
Observation:
Operate the Boiler with a full DHW Demand.
Depress the Reset switch on the underside of the Boiler for approximately 10 seconds.
Does the Boiler reset and the burner re-ignite?
Note:
The inner front case has to be in position for boiler to complete ignition sequence.
Depress the Reset switch on the underside of the Boiler for approximately 10 seconds.
Does the Boiler reset and the burner re-ignite?
Note:
The inner front case has to be in position for boiler to complete ignition sequence.
