Isolate Mains Power to appliance as per TOPs P4
Observation:
Is flow rate adjuster correctly adjusted?
Fully open the flow adjuster.
PASS this test if flow rate does NOT increase.
FAIL this test if flow rate increases to correct rate.
Notes:
The flow adjuster is located on the diverter valve top cover.
There is a quarter of a turn between fully open and fully closed.
Fully open the flow adjuster.
PASS this test if flow rate does NOT increase.
FAIL this test if flow rate increases to correct rate.
Notes:
The flow adjuster is located on the diverter valve top cover.
There is a quarter of a turn between fully open and fully closed.
