Set Appliance State:
| Isolate Mains Power to appliance as per TOPs P4 |
Set Multimeter to DC Volts
Turn Hot Water Tap On
Gain access to PCB (use Insulation Mat as required)
Flow rate set @ 3 litres/min
Flow rate set @ 3 litres/min
| WARNING! - Mains voltage is expected during test follow TOPs P4 live testing procedure |
Measurement:
Measure for DC voltage across pin 1 of connector X10 and a suitable earth connection.
Expected voltage approximately 3.0 Vdc (see note).
Note.
Connector & pin numbers are printed on the PCB.
Expected voltage approximately 3.0 Vdc (see note).
Note.
Connector & pin numbers are printed on the PCB.
