Set Appliance State:
| Isolate Mains Power to appliance as per TOPs P4 |
Remove the retaining clip which
holds the diverter motor in place
holds the diverter motor in place
Observation:
Check the diverter spindle for free movement, using a flat bladed screwdriver it should be possible to press the spindle in with about 20mm travel.
There should be resistance from the spring forcing the spindle back out to its rest position.
There should be resistance from the spring forcing the spindle back out to its rest position.
Isolate as per TOPs P4
and refit as necessary
