Set Appliance State:
| Isolate Mains Power to appliance as per TOPs P4 |
Remove the microswitch from the top of the diverter valve and place in a safe position.
Observation:
With the aid of a mirror inspect the spindle at the hole where the microswitch fits.
It should be fully extended as shown in the "tap OFF" picture.
Turn hot tap on with a flow rate of at least 2.5 litres a minute.
Inspect the spindle, it should have moved so that only 1-2mm of the spindle is visible, as shown in the "tap ON" picture.
It should be fully extended as shown in the "tap OFF" picture.
Turn hot tap on with a flow rate of at least 2.5 litres a minute.
Inspect the spindle, it should have moved so that only 1-2mm of the spindle is visible, as shown in the "tap ON" picture.
Isolate as per TOPs P4
and refit as necessary
