INFORMATION USER INTERFACE (DETAILED)

The display will sleep if no button is pressed but it can be woken up by a 1 second press on the ok button.
The service/installer menu can be access by pressing and holding the radiator and tap symbols simultaneously for 3 seconds.
Fault codes are reset by pressing the up and down arrows simultaneously until the display changes indicating reset.
Chimney sweep is activated by pressing and holding the ok button for 5 seconds.

wc greenstar style 8700 j66888 dis initilisation.gif

Menu Button
(Opens menu or returns to standby screen)

Up and Down Arrows
(Used to move up and down through options or settings)

Back Arrow
(Returns to previous screen)

Ok Button
(To accept changes / select options)

Tap Button
(Adjustment of hot water settings including preheat)

Radiator Button
(Adjustment of heating flow temperature)
