XSol Diagnostic System

OBSERVATION DISCONNECT X6

Set Appliance State:

Isolate Mains Power to appliance as per TOPs P4

Disconnect X6 from the PCB

WARNING! - Mains voltage is expected during test follow
TOPs P4 live testing procedure

Mains Power On

Observation:

Does the backlight now work?

id logic combi esp1 743413 pcb low voltage connectors.jpg

id logic combi² c30 m07865 pcb x6 disc.jpg

id logic combi² c30 dis standby.jpg

id logic combi² c30 case off pcb showing.gif
