Set Appliance State:
| Isolate Mains Power to appliance as per TOPs P4 |
Connect the air pressure switch charge kit to
+ve connection on the air pressure switch
Note the operating pressure indicated on the pressure switch
+ve connection on the air pressure switch
Note the operating pressure indicated on the pressure switch
| WARNING! - Mains voltage is expected during test follow TOPs P4 live testing procedure |
Measurement:
Ensure the performance tester reads 0mb.
Increase the pressure via the syringe to that indicated on the pressure switch.
(it is permissible to increase the pressure a further 50% if necessary)
Once pressure switch has made (audible click should be heard)
return pressure back to 0mb.
Attempt to reset boiler, does the boiler now reset?
Notes:
This fault code is known to appear when a new PCB is fitted, making the APS resets its position for the PCB and allows the board to reset.
100Pa (Pascals) = 1millibar
Increase the pressure via the syringe to that indicated on the pressure switch.
(it is permissible to increase the pressure a further 50% if necessary)
Once pressure switch has made (audible click should be heard)
return pressure back to 0mb.
Attempt to reset boiler, does the boiler now reset?
Notes:
This fault code is known to appear when a new PCB is fitted, making the APS resets its position for the PCB and allows the board to reset.
100Pa (Pascals) = 1millibar
