Set Appliance State:

Isolate Mains Power to appliance as per TOPs P4
Set Multimeter to Resistance Set meter to measure resistance
Remove connector X3 from PCB
Remove Diverter Head from its connector

Measurement:

Test the resistance of each wire from one end of the harness to the other. Each wire should show short circuit. A high resistance or O.L would indicate a faulty harness
