Set Appliance State:
| Isolate Mains Power to appliance as per TOPs P4 |
Remove the wires from the air pressure switch (noting their locations)
Measurement:
Measure the resistance between the common (3) and normally closed (1) terminals.
Continuity / zero resistance should be measured.
Note:
Terminals are numbered on the air pressure switch.
Continuity / zero resistance should be measured.
Note:
Terminals are numbered on the air pressure switch.

Isolate as per TOPs P4
and refit as necessary
