Set Appliance State:
Mains Power Off
Ensure no demands
| WARNING! - Mains voltage is expected during test follow TOPs P4 live testing procedure |
Observation:
Reset the appliance as necessary.
Every time mains power is reinstated the appliance should complete a self check of approx. 30 seconds.
The pump should begin to run approx. 3 seconds after the power is turned on and then run for a further 10 seconds.
The fan should also run at a constant speed, however, it if behaves differently a fault code will be displayed C7 FAULT CODE.
Once the self check has completed, press the info button once.
The boiler should be in status mode 203 or 204.
If a fault code or different status is displayed click Here to go to fault code list.
Some faults will not be displayed without clicking on the info button.
Every time mains power is reinstated the appliance should complete a self check of approx. 30 seconds.
The pump should begin to run approx. 3 seconds after the power is turned on and then run for a further 10 seconds.
The fan should also run at a constant speed, however, it if behaves differently a fault code will be displayed C7 FAULT CODE.
Once the self check has completed, press the info button once.
The boiler should be in status mode 203 or 204.
If a fault code or different status is displayed click Here to go to fault code list.
Some faults will not be displayed without clicking on the info button.
