Set Appliance State:
| Isolate Mains Power to appliance as per TOPs P4 |
Set Multimeter to Resistance
Disconnect mains in live plug (bottom left)
Disconnect mains in neutral plug (top centre)
Disconnect mains in neutral plug (top centre)
Measurement:
Check for continuity (zero resistance) between the L connection at the mains terminal block to the brown wire at the disconnected live plug.
Check for continuity (zero resistance) between the N connection at the mains terminal block to the blue wire at the disconnected neutral plug.
Inspect harness and plugs for good overall condition.
Note:
Overheat stat may not be present,
this does not affect test.
Check for continuity (zero resistance) between the N connection at the mains terminal block to the blue wire at the disconnected neutral plug.
Inspect harness and plugs for good overall condition.
Note:
Overheat stat may not be present,
this does not affect test.
Isolate as per TOPs P4
and refit as necessary
